Bosch CC 100 M CNC control G code and M Code complete list for cnc machinists who work on CNC Mill with BOSCH CC 100 CNC control.
Contents
G-Codes Bosch CC 100 M
| G-Code | Description |
|---|---|
| G0 | Positioning in rapid |
| G1 | Linear interpolation at programmed feedrate |
| G3 | Circular interpolation, clockwise |
| G3 | Circular interpolation, counter-clockwise |
| G4 | Dwell in seconds |
| G5 | Circular interpolation with tangential entry |
| G6 | Linear interpolation in rapid with extended IN POS range |
| G17 | Plane selection X/Y |
| G18 | Plane selection Z/X |
| G19 | Plane selection Y/Z |
| G20 | Setting pole for polar coordinates |
| G21 | Subprogram call-up depending on I/F signal |
| G22 | Subprogram call-up, unconditional |
| G23 | Jump to program label depending on I/F signal |
| G24 | Jump to program label, unconditional |
| G25 | Field limitation, setting minimum values |
| G26 | Field limitation, setting maximum values |
| G27 | Cancelling field limitation |
| G36 | Scale factor switching |
| G38 | Switch on programmable mirroring |
| G39 | Switch off programmable mirroring |
| G40 | Cancelling tool radius compensation |
| G41 | Tool radius compensation to the left of the path |
| G42 | Tool radius compensation to the right of the path |
| G53 | Cancel zero shift |
| G54 to G59 | Switch on zero shift |
| G61 | ‘In Position’ function on |
| G62 | ‘In Position’ function off |
| G63 | Feedrate and spindle speed set to 100% |
| G64 | Feedrate applies to contour on circular contours |
| G65 | Feedrate applies for tool centre path |
| G66 | Feedrate/spindle speed can be modified via pot. |
| G68 | Auxiliary arc on outside corners |
| G69 | Intersection on outside corners |
| G74 | Referencing |
| G75 | Measuring probe |
| G80 | Cancel fixed cycles G81 to G89 |
| G81 | Drilling, centering |
| G82 | Boring with dwell |
| G83 | Deep hole drilling with positioning movements in rapid |
| G84 | Tapping with dwell |
| G85 | Boring with dwell/oriented spindle stop |
| G86 | Reaming |
| G87 | Thread milling |
| G90 | Input in absolute dimensions |
| G91 | Input in incremental dimensions |
| G92 | Setting position stores / Setting top limit for spindle speed |
| G93 | Time programming |
| G94 | Feedrate direct in mm/min |
| G95 | Feedrate in mm/rev |
| G96 | Automatic calculation of cutting speed |
| G97 | Direct spindle speed programming |
| G99 | Subprogram end |
| G800 to G869 | Customer cycles: call-up via G-functions with corresponding numbers |
| G890 | Intersection circle/circle |
| G891 | Intersectin line/circle |
| G892 | Rounding corners (3 points) |
| G893 | Rounding corners (2 angles) |
| G894 | Chamfering |
| G895 | Calculation of end point of arc |
| G896 | Transition point arc/arc tangential |
| G897 | End point of straight line |
| G898 | Intersection line/line |
Trumpf Bosch Cc200 Manual User
M-Codes Bosch CC 100 M
Trumpf Bosch Cc200 Manual 2016
| M-Code | Description |
|---|---|
| M0 | Program stop after execution of the block |
| M2 | Main program end, cycle end |
| M3 | Main spindle on CW |
| M4 | Main spindle on CCW |
| M5 | Main spindle stop/coolant off |
| M6 | Call-up of the automatic tool change cycle (cycle 77) |
| M13 | Main spindle on CW, Coolant on |
| M14 | Main spindle on CCW, Coolant on |
| M19 | Orientation of main spindle to fixed position |
| M19(S…) | Orientation of main spindle to programmable position (degrees) |
| M21 | Call0up of MTB cycle 76 |
| M22 | Call-up of MTB cycle 75 |
| M30 | Program end with return to beginning (continuation with Cycle Start) |
| M40 | Automatic gear range selection |
| M41-44 | Selection of fixed gear range 1 to 4 |
| M98 | SINGLE BLOCK command is not accepted |
| M99 | SINGLE BLOCK command is possible, i.e. the effect of M98 is cancelled |
10,4” TFT replacement monitor for TRUMPF TRUMATIC 120, 235, 240, 240 ROT
This 10.4″ industrial monitor replaces 12″ CRT monitors fitted to the Trumpf punching machine and nibbler, Trumpf Trumatic 120, 235, 240, 240 Rotation and Trumatic 500 (TC500R). These Trumpf machines have a Bosch Trumagraph CC200 or CC220 control inside.
The TFT monitor was designed to be electronically and mechanically compatible with the original Bosch control and can therefore be swapped out easily with a few “Plug & Play” steps.
The monitor will be connected with a 15 pin HD D-Sub video connector. An adapter cable is supplied with the monitor.
